Leírás és Paraméterek
| Model | 23HS8430D8P1-C |
| Type | Hybridschrittmotor |
| No. of phase | 2 |
| Shaft Diameter | 8mm |
| Motor Length | 80mm |
| Step Angle ( °) | 1,8 |
| Rated Voltage (V) | 3,3 |
| Rated Current (A) | 3,0 |
| Phase Resistance (Ω) | 1,1 |
| Phase Inductance (mH) | 4,9 |
| Holding Torque (N.m) | 2,2 |
| Detent Torque (N.cm Max) | 7 |
| Rotor Torque (g.c㎡) | 480 |
| Lead Wires (NO.) | 4 |
| Motor Weight (g) | 1100 |
